Section 12

Parts List

20413146

8-2012/Rev 12

12-10

Table 12-5

Pneumatic Valve/Actuator Assembly, Normally Open

10184760

Item

Part

Number Description Quantity Item

Part

Number Description Quantity

1 10189181 Valve Body 1 10189553 Actuator Assembly, Normally Open

2 10178697 Valve Seat 1 6 BV401184 Pneumatic Cylinder 1

3 20435636 Valve Stem 1 7 BV601184 Cylinder Head 1

4 10188233 Backup Ring, Brass 1 8 BV501184 Piston 1

5 20428052 Seal Assembly 1 9 10187250 Backup Ring, SST 1

10 10074714 O-Ring, 2.44 x 2.63 x .09 1

11 10074565 O-Ring, 2.25 x 2.38 x .06 2

05116017 Rebuild Kit

Includes Items 2, 3, 4, 5, 10 and 11
