Diaphragm pump N96 Installation and connection
Translation of Original Operating and Installation Instruction, English, KNF 316836-316838 01/20
21
Connecting the pump
A marking on the pump head indicates the flow direction.
CAUTION
Risk of injury from mixing up suction side and
pressure side
Mixing up the suction side and pressure side can
result in breakage of connected components on
the suction side and pressure side.
à Observe the marking of inlet and outlet on
the pump head.
1. Remove the protective plugs from the hose connection threads.
2. Connect the suction line and the pressure line (for mounting dimen-
sions, see Chapter 4 Technical data).
3. Lay the suction line and pressure line with a descent so that no con-
densate can run into the pump.
Pneumatic noises can be reduced or dissipated by using a silencer
(see Chapter 11.2 Accessories).
Secure the pressure-side connections with a fastener (e.g., hose/
pipe clamp) to prevent the hoses from slipping down from the con-
nection.
