Technical data Diaphragm pump N96
8 Translation of Original Operating and Installation Instruction, English, KNF 316836-316838 01/20
4 Technical data
Technical data
Pump materials
Assembly Material
KN
Material
KT
Pump head PPS PPS
Diaphragm EPDM PTFE-coated
Valves FKM FKM
Tab.5 Pump materials KN/KT variant
Pneumatic values
N96KNDC-B-M
Parameter Value
Max. permissible operating pressure
[bar rel*]
2.5
Ultimate vacuum [mbar abs.] <100
Flow rate at atm. pressure [l/min]** 8.5 ± 10%
Tab.7
*Bar rel related to 1013 hPa
**Liters in standard state (1013 hPa, 20°C)
N96KTDC-B-M
Parameter Value
Max. permissible operating pressure
[bar rel*]
2.5
Ultimate vacuum [mbar abs.] <130
Flow rate at atm. pressure [l/min]** 7.0 ± 10%
Tab.9
*Bar rel related to 1013 hPa
**Liters in standard state (1013 hPa, 20°C)
Pneumatic connections
Pump type Value Value
N96KNDC-B-M G1/8 NPT 1/8
N96KTDC-B-M G1/8 NPT 1/8
Tab.11
