Diaphragm Pumps NMP 830, NMP 850 Technical Data
KNF Neuberger BA121556-121559 NMP830_850-EN 0221.doc
Translation of original Operating and Installation Instructions, English, 7
NMP 830 KTDC, NMP 830 KTDC-B
NMP 850 KTDC, NMP 850 KTDC-B
NMP 850 KTE, NMP 850.1.2 KTDC-B
Assembly
Material
Head plate; intermediate plate
PPS
Housing
PA-GF50
Valve plate
FFPM
O-ring
FPM
Diaphragm
PTFE coated
Tab. 7
