8
■ Preparations■ Preparations
●Battery Installations ●Battery Level Warning
Battery Box
1.
2.
3.
R03/AAA/UM4
Batteries (4pcs.)
*Sold separately
Battery Box Cover
Press the tab on the bottom of the transmitter
to open battery box cover.
Remove the lock to pull out
battery box.
Install four R03/AAA/UM4
alkaline batteries while noting
their polarity, then replace
battery box.
Use batteries which have adequate remaining
capacity. Weak batteries mean lower transmitting
power and may result in malfunctions.
A warning will be displayed with the LED ashing and
an alarm will sound when battery voltage is less 4v.
When you see this warning, stop your model in a safe
area, turn it off and install new transmitter batteries.
When using a Li-Po / Li-Fe battery, be sure to
change the expansion battery setting (p.41)
because it is necessary to warn before the voltage
drops to 4V.
To Next Page
