OPERATING INSTRUCTIONS
3. Moving the Air Compressor
3
CAUTION: To avoid personal injury, DO NOT
grab only the sliding handle (K) to lift the whole unit.
If you want to lift the unit, please make sure you
(K).
Use the following instructions to use the sliding
handle (K) and wheels to move the unit.
a. Unlock the two cam locks (L) as shown in the
illustration.
b. Slide the handle (K) upward to the desired
height.
c. Lock the two cam locks (L) in place.
K
L
H1
CARE AND MAINTENANCE
WARNING: To avoid personal injury, always shut off and unplug the unit and relieve all air
pressure from the system before performing any service on the air compressor.
Regular maintenance will ensure trouble-free operation. The items listed here should be inspected on
a regular basis.
On a daily basis, drain the tank to prevent corrosion from forming inside
the tank. Drain the condensation at the end of every day. Wear protective
goggles. Relieve the air pressure in the system and then open the drain
valve (I) on the bottom of the tank.
On a daily basis, pull the pressure relief valve (G) to ensure that it is
operating properly and to clear the valve of any possible obstructions.
soapy water.
Check all connections to ensure they are tight. A small leak from any part of the compressor
will reduce the unit’s performance. Spray a small amount of soapy water around the area of the
suspected leak with a spray bubble. If bubbles appear, repair or replace the faulty component.
Do not overtighten any connections.
Before storing the unit for a long period, do the following:
Use an air blow gun (not included) to clean all dust and debris from the compressor.
Disconnect and coil the power cord.
Pull the pressure relief valve to release all pressure from the tank.
Drain all moisture from the tank.
Cover the entire unit to protect it from moisture and dust.
I
