INSTRUCCIONES DE ENSAMBLAJE
10. Instale la perilla para ajustar la altura (FF) y el
Tornillo Phillips de cabeza redonda M8 (GG) a la
rueda para ajustar la altura.
Herramientas utilizadas
GG
Tornillo Phillips de
cabeza redonda M8
Perilla para
ajustar la altura
FF
2 in. Bolt
Qty. 2
Nut
(preassembled
to lower right
leg assembly)
Qty. 2
Washer
(preassembled
to lower right
leg assembly)
Qty. 4
3 in. Cap screw
Qty. 6
Height adjustment
knob
Qty. 1
8 mm Hex bolt
Qty. 1
1-1/2 in. Cap screw
Qty. 4
Spacer
Qty. 6
Nut
Qty. 10
1 in. hex bolt
Qty. 2
AA BB CC
DD
EE
JJ
KK
FF GG
HH
