13
ASSEMBLY INSTRUCTIONS
5. To Install the cutting line
Note: For 0.080 in. (2.0 mm) nylon line, do not put
more than 13 feet of cutting line in at a time.
a. Remove battery before installing new line.
b. Line up the slots on the bump knob (P) with the
slots on the spool cover (L).
c. Insert line through the eyelet (N). Push
line until it exits the opposite string head hole.
d. Pull the line through until there is an equal amount
of line on each side.
e. Turn the bump knob (P) counterclockwise to begin
winding the string into the string head (S). Leave
approximately 5 inches of string protruding out of
each side of the head.
Slots
