● Press the arbor lock button (R - Fig. 14), holding
it in rmly while turning the wheel wrench
counterclockwise to loosen.
● Remove the arbor nut (MM) and outer wheel
ange (1). Do not remove the inner wheel
ange (2). (Fig. 15)
WARNING: If the inner ange (2) has been
removed, replace it before placing wheel on
arbor. Failure to do so could cause an accident
since the wheel will not tighten properly. Never
use a wheel that has openings, grooves, or
teeth on this tool.
● Place the 7 in. cutting wheel (E) on the
arbor (3) with the wheel ts ush against
the inner ange (2) and the rotation arrow is
pointing in the correct direction. Make sure the
cutting wheel is installed between the two water
nozzles (OO).
NOTICE: Two water nozzles (OO) come
installed on this product. The hole in each
nozzle should face the cutting wheel.
● Replace the outer wheel ange (1) against the
wheel and on the arbor. Make sure the wheel
ts ush against the inner wheel ange and the
outer wheel ange, and the rotation arrow is
pointing in the correct direction and matches the
arrow on the outside of the upper guard.
● Replace the arbor nut (MM) on the arbor and
place the wheel wrench (MM) on the arbor nut.
Press the arbor lock button (R - Fig. 14), holding
it in rmly while turning the wheel wrench
clockwise to tighten.
● Close the upper wheel guard (LL) and tighten
the wheel guard lock knob (JJ). (Fig. 13)
15
Do not remove
inner ange
R
3
2
1
E
OO
MM
REMOVING THE TILE CUTTING WHEEL (FIG. 13, 14, 15)
WARNING: To avoid injury from an accidental start, make sure the switch is in the OFF
position and the plug is not connected to the power source outlet.
● Disconnect the saw from the power source.
● Move the sliding table to the front of the saw.
● Loosen the cutting head lock knob (DD) and then pull out the hold-down latch (FF) to raise the
cutting head assembly to its upmost position. Release the hold-down latch (FF) and tighten
the cutting head lock knob (DD). (Fig. 13)
● Loosen the wheel guard lock knob (JJ) and open the upper wheel guard (LL).
● Place the wheel wrench (NN) on the arbor nut (LL).
● Press the arbor lock button (R - Fig. 14), holding it in rmly while turning the wheel wrench
counterclockwise to loosen.
● Remove the arbor nut (MM), outer wheel ange (1) and cutting wheel (E). Do not remove the
inner wheel ange (2). (Fig. 15)
