16
NOTE: Under normal operating conditions, it should
not be necessary to replace the auger belt. However,
should the auger jam or malfunction, the belt could be
damaged. To replace the belt, follow the instructions.
NOTE: Determine the left and right hand side of the
snow thrower by standing behind the unit in the normal
operating position.
• Install the new scraper bar and fasten it securely to
the snow thrower with the screws.
• Open the left side plate by removing six screws.
• Use your right hand to turn the rib side of the belt
up and pull upwards while turning the auger pulley
counterclockwise with your left hand. The belt can
be easily removed from the pulley.
• Put the belt on the drive pulley rst and then place
the belt at the lower end of the auger pulley.
3. REPLACING THE BELT
The screws that secure the scraper bar
Belt
Auger pulley Drive pulley
