Kobalt F226VWLVP User Manual

9
1 1 Cover, Intake Filter 1
2 1 Element, Intake Filter 1
3 1 Housing, Intake Filter 1
4 Head, Cylinder 1
5 Bolt, m6 x 1 x 35mm SHCS 4
6 Washer, Lock 6mm 4
7 Fitting, 90 degree Elbow,
3/8” npt x 3/8 Flare 1
8 4 O-Ring, Head 1
9 4 Bolt, m3 x 4 x 5mm HFHS 2
10 4 Valve, Retainer, Outlet 1
11 4 Valve, Outlet 1
12 4 Valve Plate 1
13 4 O-Ring, Cylinder 1
14 4 Valve, Intake 1
15 4 Valve, Retainer, Intake 1
16 2 Cylinder 1
17 Screw, m6 x 1 x 12mm HFHS 6
18 E103492 Shroud, F2, Full, Rear, Gray 1
19 Pump/Motor 1
20 Bolt, m8 x 1 x 16mm 4
21 Washer, Lock, 8mm 4
22 Washer, Flat, 8mm 4
23 Nut, m8 x 1 x 25mm ZDC 4
24 E103287 Tube, Relief 1
25 E101362 Valve, Check 90 degree, Left 1
26 Eccentric 1
27 Bearing, Piston 1
28 2 Screw, m5 x 0.8 x 16mm SHCS 1
29 2 Piston Cap 1
30 2 Piston Ring 1
31 2 Piston 2
32 2 Nut, m5 x 8mm 1
33 2 Bolt, m5 x 0.8 x 25mm 1
34 E100297 Fan 1
35 Washer, Flat, 6mm 1
36 Bolt, m6 x 1 x 16mm SCHS 1
37 E103491 Shroud, F2, Full, Front, Gray 1
38 E103286 Tube, Outlet 1
39 Washer, Flat, 6mm 2
40 Bolt, m6 x 1 x 16mm SHCS 2
41 Handle, Grip 1
42 E103485 Handle 1
43 E101733 Gauge, 2”, 150 Redline,
Back Feed, Kobalt 2
44 E100307 Quick Connect, One Hand 1
45 Regulator 1
46 Nipple, 1/4 npt x 35mm 2
47 E102595 Safety Valve, 165 psi 1
48 E100957 Pressure Switch, 150 psi 1
49 Bolt, m8 x 1.25 x 25mm 4
50 Washer, Flat, 8mm 4
51 Nut, Insert m8 4
52 Tank, Asm 1
53 3 Nut, 10mm 2
54 3 Wheel, 7” Kobalt 2
55 3 Bolt, m10 x 1.25 x 20mm 2
56 3 Hubcap, Kobalt 2
57 E101717 Drain Valve, 1/4-Turn 1
58 Nut, m8 x 1 x 25mm ZDC 2
59 E101805 Isolator, Kobalt 2
60 Washer, Flat, m8 2
61 Bolt, m8 x 1 x 20mm 2
NOTE: Any part number field without a number listed is not available.
Descriptions are provided for reference only.
Air Compressor Item # 37296 / Model # F226VWLVP
Parts List
Ref. Kit Part
Description Quantity
# # Number
Kit numbers, descriptions, and included components are listed below:
Kit # Part # Kit Name Reference #
1 E101611 Air Filter Kit 1-3
2 E103495 Piston Kit 16, 28-33
3 E103496 Wheel Kit
(One Wheel Asm per Kit) 53-56
4 E103497 Valve Plate Assy Kit 8-15
For replacement parts, please call 1-800-628-8815 ext. 5000.
