11
OPERATING INSTRUCTIONS
5. To Start/Stop the Sprayer
a. To turn the sprayer ON, place the ON/OFF
switch (D) into the ON position “I”.
b. To start the ow of liquid at the spray wand,
depress the trigger on the handle (H).
c. To stop the ow of liquid at the spray wand,
release the trigger.
d. To turn the sprayer OFF, place the ON/OFF
switch into the OFF position “O”.
Lock-On Trigger
The lock-on trigger is convenient when spraying
for an extended period of time or when covering a
large area.
a. To lock the trigger on, depress the trigger and
slide it forward.
b. To release the lock-on, depress the trigger and
slide it backward.
NOTICE: Make sure the trigger is not locked on
before inserting the battery pack into the sprayer.
6. Adjusting the Spray Nozzle
The spray nozzle can be adjusted from a stream to
a fan spray.
a. Remove the battery pack from the tool.
b. Loosen the nozzle for a stream.
c. Tighten the nozzle for a fan spray.
5a
D
5b
H
6
G
Loosen
Tighten
