15
OPERATING INSTRUCTIONS
7. LED Work Light
The circular saw is equipped with a LED work
light (X). It will illuminate when the trigger switch
is depressed. This provides additional light on the
surface of the work piece for operation in lower-light
areas.
The LED work light will turn off after the trigger
switch is released.
8. Using the Vacuum Adapter
The vacuum adapter allows to be connected to a
1-1/4 in. diameter vacuum hose to help keep the
work area clean.
a. Remove the battery pack.
b. Attach the vacuum hose to the vacuum adapter
(Z).
c. The vacuum adapter can be rotated to a
desired position along the slot on it.
d. Disconnect the vacuum hose when nished
cutting.
WARNING
• Never allow a vacuum hose to interfere with the lower guard or cutting operation.
7
X
8
Z
