4
PACKAGE CONTENTS
Saw Chain
A loop of chain with cutting teeth, that when it is driven by the powerhead and supported by the
guide bar, cuts wood.
Kickback Guard
Protects the operator from being hurt by the saw kickback during operation.
Guide Bar
Supports and guides the saw chain.
Side-cover Knob
Locks/unlocks the side cover using foldable tab.
Side Cover
Covers the chain sprocket and secures the guide bar.
Cap Tab
Foldable cap tab assists in tightening or loosening of the oil-tank cap.
Oil-tank Cap
Seals the oil tank.
Oil Tank
Holds bar and chain oil.
Chain Sheath
The chain sheath prevents the operator from coming in contact with the sharp chain teeth
when the tool is not in use. It also helps to protect the chain teeth from being nicked or
damaged during transportation and storage.
WARNING
• Remove the tool from the package and examine it carefully. Do not discard the carton or any
packaging material until all parts have been examined.
WARNING
• If any part of the tool is missing or damaged, do not attach the battery to use the tool until
the part has been repaired or replaced. Failure to heed this warning could result in serious
injury.
