12
OPERATING INSTRUCTIONS
Adjusting the Cutting Swath
The string trimmer is factory set at 15-inch (38 cm)
cutting swath. To decrease the cutting swath from
15 to 13 inches (38 to 33 cm):
a. Remove the battery pack from the tool.
b. Use a Philips head screwdriver (not included) to
loosen and remove the two screws that secure
the line-cutting blade (B) to the guard (Fig. 5c).
c. Move the blade and align the two holes in the
blade with the other two holes in the guard
(Fig. 5d).
d. Insert the two screws and tighten them
securely.
5d
13 inch (33cm)
5c
Screws
15 inch (38cm)
B
