PACKAGE CONTENTS
A
B
C
E
F
I
G H L K
N
J
PART DESCRIPTION PART DESCRIPTION
A Lock-off button I Adjusting lever
B Variable-speed trigger switch J Screw knob
C Rear handle K Guard
D hinge L Line-cutting blade
E Trimmer shaft M Screws (2)
F Trimmer head N Hex wrench
G Bump knob O Bolts (2)
H Front-assist handle P Plain washer (2)
WARNING
• Remove the tool from the package and examine it carefully. Inspect the tool carefully to
make sure that no breakage or damage occurred during shipping. If any parts are damaged
or missing, please return the product to the place of purchase. Do not discard the carton or
any packaging material until all parts have been examined.
• If any part of the tool is missing or damaged, do not connect the battery to the tool or use
the tool until the part has been repaired or replaced. Failure to heed this warning could
result in serious injury.
