2-106
ï¼»2. MACHINE FAMILIARIZATIONï¼½
2.15 OTHER ACCESSORIES
2.15.1 TOOL BOX
Use the tool box for storing tools and fixtures. The
storage place is on right side (1) of the machine.
Use the starter key to release the lock on the door, and
hold it with the stay.
After using tools, remove the stay, close the cover, and
lock it with the starter key.
2.15.2 GREASE GUN HOLDER
This is on the left rear of the machine.
When the gun is not used, put it on this holder.
2.15.3 GUARD/SIDE DOOR (WITH LOCK)
Be sure to stop the engine before opening the engine hood, battery cover, and side cover, etc.
The engine hood, fuel inlet, right and left side doors, and cab door covers are provided with the lock mechanism.
To open/close them, use the starter key. When using the starter key, fully insert it and then turn it. If it is not fully
inserted, it may be broken.
Copyright©2020 Kobelco Construction Machinery Co.,Ltd. All rights reserved. [S2YY00041ZE03] [0701CsCshWbYs]
