6505 Control Head Kobelt Manufacturing Co. Ltd.
Rev A mnl6505.docx 16 of 18
ITEM QTY. PART NUMBER DESCRIPTION
1 1 6505-SUB-TB SUB-ASSEMBLY 6505-TB
1.1 1 6505-0001-B DOME, TEXTURE BLACK
1.2 2 6505-0007-K 6505 HANDLE, CHROME
1.3 2 1101-0014 O-RING, 1/2 X 1/16, NBR70
1.4 2 6505-0005-R CAM, RIGHT, 3 DETENTS
1.5 2 2009-0011 DETENT PLUNGER
1.6 4 6509-0007 DETENT PLUG
1.7 2 2542-0008 FRICTION PLUG
1.8 2 1201-0062 SPRING, DETENT
1.9 2 1201-0205 SPRING, FRICTION
1.1 2 YP-3264-1 SPUR GEAR - DELRIN; 32DP - 64T, STYLE A
1.11 4 1012-0606 SCREW, PAN HD, PHL DRIVE, 6-32 x 3/8IN, 18-8 SS
1.12 2 1016-0804 SCREW, SET, SKT HEAD, CUP POINT, 10-24 X 1/4, 18-8 SS
1.13 2 POT-5 POTENTIOMETER; 22MM, 5K, 1 TURN
1.14 2 1023-0214 WASHER, .622 X .445 X .030 IN, STEEL
1.15 2 6639-0001 WASHER, FLAT, 10MM X 2MM, AISI 304
1.16 2 YPB-3232-3/16 SPUR GEAR - DELRIN; 32T, 32DP, 3/16in ID, BRASS INSERT
1.17 2 1041-700601 SET SCREW - SKT HD CP; #6-32 X 1/8, F912, B.O.
1.18 2 1024-0814 SPRING PIN; 3/16 DIA X 7/8 LG, 420 SS
1.19 4 1023-0234 FLAT WASHER: 5/8 X 7/8 X .015
2 1 6505-0003 SPACER; CONTROL HEAD ELECTRICAL BOX
4 1 6505-0004-L COVER PLATE LARGE
5 1 6505-0004-S COVER PLATE, SMALL
6 2 6009-7840 CABLE GLAND, 1/2 NPT, .39 - .55 CORD, NYLON
7 1 6505-1001-CBOARD-P PCB ASSEMBLY - CONTROL HEAD
8 8 1012-0604 SCREW, PAN HD PHILLIPS, 6-32 X 1/4, 18-8
9 2 1012-0608 SCREW, PAN HD, PHL, #6-32 x 1/2, 18-8
11 1 6012-0016 SWITCH PAD
12 1 6009-4102 CONNECTOR - PLUG; 3.5MM, 2POS, STRAIGHT
13 1 6009-4104 CONNECTOR - PLUG; 3.5MM, 4POS, STRAIGHT
14 1 6009-4105 CONNECTOR - PLUG; 3.5MM, 5POS, STRAIGHT
