7
Product connection diagram
■ System configurations(Camera Mode)
■ System configurations(Guard Mode)
DC Door opener
DC Door opener
External power input
External power input
2wire
2wire
Polarized 4wire
Polarized 4wire
Door Camera
Door Camera
KCV-434SD
DC Door opener
Lobby Phone
Guard Phone
External power input
2wire
4wire
Polarized 4wire
Polarized 4wire
Door Camera
KVS-A4P / KVS-A8P
Reapter
KCV-434SD
