PRE-INSTALLATION PROCEDURES:
IMPORTANT: The solar panel requires full, direct sunlight to charge the battery. Clouds,
rain, snow, and other weather conditions may not allow the solar panel to completely
recharge the battery. Other obstructions such as buildings or trees may block the sun as
well.
When installing the solar panel, make sure it is aimed as described below with a
minimum amount of obstructions. If possible, mount the panel facing toward the
southern sky.
INSTALLATION PROCEDURES:
TEST THE MOTION SENSOR
Before installing the oodlight, TEST the oodlight to ensure it is working
properly.
NOTE: When the motion sensor switch is set to the TEST position, the light
will operate during the day or night. The light will stay on for 4-6 seconds after all
motion is stopped.
• PRIOR TO USE, the battery will require 12 hours of full sun (aprox. 3 to 7 days) to
completely charge with the control switch in the OFF position. Plug the solar panel cable
into the connector extending from the bottom of the battery case. If possible, aim the
solar panel toward the south and tilt it approximately 50° from horizontal. If the solar
panel cannot be aimed toward the south, then tilt the panel approximately 30° .
• Actual operating time will vary depending upon how frequently the light is turned on by
the motion sensor.
INSTALLATION INSTRUCTIONS:
Estimated installation time: 30 minutes
