1-2 May 4, 2005
Setting Up the Printer
Before You Begin
IMPORTANT: Your KODAK Photo Printer comes with several power cables.
Be sure to select the correct power cable required for your
country.
Have the following items available before you begin your printer setup:
• KODAK Photo Print Kit 6800/4R or KODAK Photo Print Kit 6800/6R which
contains the correct paper and ribbon for the best print quality and print
life from your printer. See Appendix A for details on the Photo Print Kit
(sold separately).
• USB cable (included).
IMPORTANT: The printer weighs 56 lb (25 kg) and is heavier at the front
than at the back. Use caution when lifting or moving the
printer.
Recommended Air
Flow Clearances
If you plan to set up the printer in a restricted space, such as in a cabinet,
refer to the following illustration for the recommended air flow clearances for
this type of setup.
50 mm
50 mm
50 mm
10 mm
