Kodak EASYSHARE S730 - Replacing the battery

Appendix
www.kodak.com/go/support
45
Replacing the battery
To purchase a replacement battery (model KAA3HR-2300), visit
www.kodak.com/go/accessories.
Remove the existing battery
Place the frame screen-down on a flat,
protected surface.
Rotate the stand away from the
battery door.
Remove the screw.
Remove the battery door.
Slide the battery out and unplug the
connector.
Pull on the connector, not the wires.
2
4
3
Disconnect the power cable.
1
