Maintaining Your Printer
68 www.kodak.com/go/aiosupport
7. Remove the plastic protective cap.
IMPORTANT: Be careful not to scratch or touch the copper contacts while inserting
the printhead.
8. Place the new printhead into the carriage.
9. Push firmly against the target label of the printhead until you hear a loud snap.
Copper contacts
