Kodak HERO 5.1 - Printer Overview; Printer Components

www.kodak.com/go/aiosupport 1
1 Printer Overview
This printer lets you print, copy, and scan pictures and documents. In addition, this
printer supports networking, letting you access the printer over a wireless (Wi-Fi)
network.
Components
1 Control Panel 9 Access door
2 LCD 10
Printhead with ink cartridges installed
3 USB port 11 Paper output tray
4 Power cord port 12 Paper output tray extender / paper stop
5 Duplexer 13 Scanner glass
6 Wi-Fi connectivity LED 14 Scanner lid
7 Memory card slot 15
Paper input tray
8 Front USB port 16 Left paper-edge guide
6
1 2 3 4 5
7
8
9101112
13
14
15
16
