Kodak OG-Plus3.24RM - Page 44

42
Two inverters in two phases and only one inverter for the remaining phase:
Power Connection
N
L1
P1 P2
P3
L2
L3
N
L1
L2
L3
Load
Communication Connection
Two inverters in one phase and only one inverter for the remaining phases:
Power Connection
N
L1
P1
P2 P3
L2
L3
N
L1
L2
L3
Load
Communication Connection
