Kodiak X2 User Guide
14
Using the Kodiak X2 in Dualink Parallel Mode
The Kodiak X2 can be paralleled with another Kodiak X2 to provide double the battery capacity
and double the AC output. To use Dualink Parallel Mode, follow the step below to ensure safe
operation. Not doing so could result in permanent damage to your Kodiak X2, risk of severe
shock, fire, property damage, or bodily harm and will void the warranty.
1. Begin with both units turned off.
2. Push the Dualink Parallel Switch (located on the left side of the unit) completely to the RIGHT,
so the switch is below the letter “P” on BOTH units as seen in FIGURE 1.
3. Connect the wall adapter to the AC OUTPUTS on the secondary unit, and the other end to
the AC INPUT on the primary unit, as seen in FIGURE 2
4. Turn on the Main Power Button on both units, but NOT the AC Power Button.
5. Verify the Parallel Mode Icon appears on the LCD of BOTH units, as seen in FIGURE 3.
6. Connect the desired AC load to the PRIMARY unit ONLY.
7. Turn the AC Power Button on for the PRIMARY unit, then the SECONDARY unit. Any AC loads
connected to the primary unit will be shared equally between the two units.
Figure 1 Figure 2
