SV3000, SV4000 Saybolt Viscosity Bath
Operation and Instruction Manual
- 5 -
4. Descriptions
4.1. Instrument Controls
Figure 1: Instrument Descriptions (Front)
Figure 2: Instrument Descriptions (Back) Figure 3: Timer Components (SV4000 only)
1. Power Switch. This switch controls the power to the entire unit. When the power switch is in the ON position, power is
supplied to the unit, turning on the digital temperature controller and stirrer motor.
2. Temperature Controller. The temperature controller regulates the bath temperature for the test procedure. Refer to
Section 4.3 for full operational details.
