1.10.1 Overview
Displays basic and commonly sought after information
about the generator set. This information scrolls
automatically after about 5 minutes of no user input
(pushbutton/rotary selector dial or button activity).
To change from auto scrolling to fixed display, press the
rotary dial and the main menu will appear. Press the
rotary dial again to select the first menu item Overview.
Turn the rotary dial to select the desired fixed view.
Overview (Auto Scrolling Display)
Overview ---->
##.# hr
Avg V L--L:
#.# V
Active Shutdowns
(if present)
Eng Runtime:
##.# h
Frequency:
#.# Hz
Oil Pressure:
# PSI
Battery:
##.# V
SW Version:
1.02
Active Warnings
(if present)
Genset State ######
Coolnt Temp:
### F
Next maint:
##.# h
Overview (Fixed Display)
Overview ---->
##.# hr
### V ##.# Hz
###_F ###%
### PSI ##.# V
English Display
Measurements -->
Metric Display
Measurements -->
###_ C ##.# %
#.# kPa ##.# V
1.10.2 Engine Metering
Displays engine operating data as measured by the
engine and other sensors.
Engine Metering
Engine ---->
Metering
Coolnt Temp:
### F
Eng Speed:
#R/min
Oil Pres:
# PSI
Battery:
##.# V
To Next Page
