Kohler 12RESM1 Service

TP-6196 10/09 61Section 5 ADC-RES and DC-RET Controller
8.5/12 kW
Wait about 5 seconds until the display shows the
program version number. (The number may be
different than the one shown here.)
Hold the Select button:
or
To change the voltage/frequency setting,
if necessary. See Figure 4-7.
To enter setting and step to the next parameter, engine type Ec.
To enter setting and step to SAVE.
Move the generator set master switch to the RUN
position. (The generator set engine will not start.)
Display:
or
To change the engine type,
if necessary.
U u 0 x
U u 0 1
v 1 1 3
. 0
Press:
Now release the Select button.
S A V E
Note: Shaded boxes show which number in the controller display changes when the up or down arrow
key is pressed. X in the runtime hours display above denotes any number from 0 to 9.
Press the down arrow key and then the up arrow
key 3 times to enter the configuration mode.
(This is the controller “password.”)
Controller Configurat ion Mo de:
To SAV E CHANGES.
To DISCARD CHANGES without saving.
Y E S
Now move the master switch to OFF/RESET.
n o
x x xx
Press:
“Yes” or “no” flashes when the up or down arrow is pressed and
then the controller exits the configuration mode. The display
returns to the runtime hours.
OR
E c 0 0
To enter setting and step to the next parameter, communication
setting Cn.
or
To change the communication setting, if
necessary. See Figure 4-7.
C n 0 x
Figure 5-10 Configuration Mode (system voltage/frequency, engine type, and communication parameters)
