Kohler 15CCFOZ Service Manual

TP-5606 6/02 Scheduled Maintenance 3-13
ADV-5834-B
1
2
1. Initial Coolant Fill 2. Coolant Drain
Figure 3-12. Initial Coolant Fill and Coolant Drain Locations (In-line-Radiator Model)
ADV-5834-B
1
3
2
1. Coolant Outlet (Thermostat Housing)
2. Belt Guard
3. Coolant Inlet (Water Pump)
Figure 3-13. Coolant Inlet and Outlet Connections (Remote-Radiator Model)
