Kohler 26RCAL

28 TP-7091 4/23
2.2.3 Fuel Conversion, Revised Fuel System, 14/20/26RCA/L
The revised fuel system uses a knob that controls a valve on the regulator to select the fuel type. See Figure 16 and Figure 17.
Figure 16 Revised Fuel System
Figure 17 Fuel Selection (NG Position Shown)
Fuel selector
Fuel inlet
Integral fuel solenoid valve
GM114166
Pressure port
Fuel selector
GM110973- CMP
