TP-6862 6/14 29Section 6 Electrical System
Section 6 Electrical System
Hazardous voltage.
Can cause severe injury or death.
Operate the generator set only when
all guards and electrical enclosures
areinplace.
Moving parts.
WARNING
Electrical backfeed to the utility. Hazardous backfeed
voltage can cause severe injury or death. Connect the
generator set to the building/marina electrical system only
through an approved device and after the building/marina
main switch is turned off. Backfeed connections can cause
severe injury or death to utility personnel working on power
lines and/or personnel near the work area. Some states and
localities prohibit unauthorized connection to the utility
electrical system. Install a s hip-to-shore transfer switch to
prevent interconnection of the generator set power and shore
power.
6.1 AC Voltage Connections
Make AC connections to the generator set inside the
junction box. Typically, the generator set connects to a
ship-to-shore transfer switch that allows the use of
shore/utility power when docked or generator set power
when docked or at sea. The wiring then connects to a
main circuit breaker box (panel board) that distributes
branch circuits throughout the craft. See Section 8 for
reconnection of the generator set.
6.2 Circuit Protection
The AC circuit breakers (optional) protect the wiring
from the AC circuit breakers to the vessel’s distribution
panel. AC circuit breakers trip when they detect a fault in
the output circuit.
After correcting the fault, reset the AC circuit breaker(s) by
placing them in the ON position. Restart the unit. Do not
start the unit under load. See Figure 6-1 and Figure 6-2
for AC circuit breaker ratings. The unit’s voltage
configuration determines the circuit breaker selection.
Note: Circuit breaker ampere rating and availability are
subject to change.
6.2.1 Circuit Breaker Consid erations
Mounting location. Mount the circuit breakers in the
generator set’s junction box. See Section 6.2.2.
Sizing. Use the generator set voltage/frequency
configuration to determine the circuit breaker
amperage. If the generator set voltage configuration
changes, change the circuit breaker to provide optimum
protection.
For circuit breaker application and selection
information, contact an authorized distributor/dealer.
Have a qualified electrician or technician install circuit
breakers and reconnect the generator set. Comply with
all governing standards and codes.
Amps
Max.
Voltage
Model(s)
70 600 40EOZD(C)DJ, 33EFOZD(C)J
80 600 40EFOZD(C)J, 45EFOZD(C)J
90 480 40EFOZD(C)J, 45EFOZD(C)J
100 480 55EOZD(C)J, 45EFOZD(C)J, 50EFOZD(C)J
125 480 50EFOZD(C)J, 65EOZD(C)J, 55EFOZD(C)J
125 600 33EFOZD(C)J
150 480 80EOZD(C)J, 70EFOZD(C)J
150 600 40EOZD(C)J, 33EFOZD(C)J, 40EFOZD(C)J
175 480 99EOZD(C)J, 70EFOZD(C)J 80EFOZD(C)J
175 600
40EOZD(C)J, 33EFOZD(C)J, 40EFOZD(C)J,
45EFOZD(C)J
200 600 40EFOZD(C)J, 50EFOZD(C)J, 55EOZD(C)J
250 600
50EFOZD(C)J, 55EOZD(C)J, 45EFOZD(C)J,
65EOZD(C)J, 55EFOZD(C)J, 125EOZD(C)J,
100EFOZDJ(C)J
400 600
80EOZD(C)J, 70EFOZD(C)J, 99EOZD(C)J,
80EFOZD(C)J, 150EOZD(C)J,
100EFOZD(C)J, 125EFOZD(C)J
600 600
125EOZD(C)J 150EOZD(C)J,
100EFOZD(C)J, 125EFOZD(C)J
Figure 6-1 3-Pole AC Circuit Breaker Ratings
(33--150 kW Models), Listed By Amps
