TP-5594 5/956-4 Installation
Electrical Appliance Ratings (Watts)
Blanket 50-250
Blender 600
Dryer, Hair 500-1200
Fan, Air Circulating 25-100
Fan, Furnace 270
Heater, Space 750-1500
Heater, Water 1500
Pan, Frying 1200
Percolator, Coffee 650
Radio 50-100
Television 300-750
Toaster 750-1200
Figure 6-3. Appliance Ratings (60 Hz)
Motor
Starting
Watts
Air Compressor (Small) 1500 725
Air Compressor 3/4 hp 4000+ 2000
Drill, 1/4 in. 500 250
Drill, 3/8 in. 600 350
Drill, 1/2 in. 800 600
Grinder 1/2 hp 1500 1200
Hammer, Demolition 2000 1800
Hammer, HD Rotary 1500 1200
Paint Sprayer (Airless) 400 240
Polisher, Orbit 500 360
Power Paint Roller 120 90
Power Plane 600 450
Router 900 700
Saw, Circular 6 1/2 in. 2200 1000
Saw, Circular 7 1/4 in. 2500 1200
Saw, Table 10 in. 4000 1500
Saw, Sabre (Worm Drive) 2500 1200
Sander, Belt 1500 600
Sander, Finishing 900 360
Screwdriver, Power 1000 530
Shear, 12 gauge 1800 720
Soldering Gun — 250
Vacuum Cleaner, Wet/Dry 1500 1260
Wrench, Impact 1/2 in. 2000 840
Running
Watts
Construction Tools
Figure 6-4. Construction Tool Ratings (60 Hz)
Appliance Loads
Generatorsetsin recreationalvehicles areoften usedto
furnish AC for appliances such as TV, stereo, electric
water heaters, etc. With the exception of the
resistance-type loads such as the water heater,
requirementsforappliancesareusuallylow. Suchloads
must not, however, be overlooked when figuring total
requirements. Reserve capacity should be available for
anticipated appliance loads to avoid overloading of a
set. Theaveragepowerrequirementsofsomeelectrical
appliances are listed in Figure 6-3 and Figure 6-4.
Kilowatt Derating
All units arerated 1.0 power factor. The kilowatts of the
generator set will decrease 3.5% per 1000 ft. (305 m)
above 500 ft. (152 m) above sea level. Derate 1% for
every 10_F (5.5_C) above 85_F (30_C).
Compartment Size
When planning compartment size requirements, allow
theminimumclearances for cooling of the generatorset
as shown in Figure 6-5.
NOTE
Since the sets are flexibly mounted, the minimum
clearanceswillassurethatthesidesofthecompartment
and the set will not rub while the set is in operation or
while the vehicle is in transit.
Front 1 1/2 in. (38 mm). . . . . . . . . .
Side 1 1/2 in. (38 mm). . . . . . . . . . .
Top 1 1/2 in. (38 mm). . . . . . . . . . . .
Rear 1 1/2 in. (38 mm). . . . . . . . . . .
Figure 6-5. Minimum Clearance Requirements
NOTE
Minimum clearances listed for cooling air circulation.
Additional clearance is required for routine servicing of
the generator set.
