Kohler Command CH670 Service Manual

CARBURETORS
WARNING
Gasoline is extremely ammable and its vapors can
explode if ignited. Store gasoline only in approved
containers, in well ventilated, unoccupied buildings, away
from sparks or ames. Spilled fuel could ignite if it comes
in contact with hot parts or sparks from ignition. Never use
gasoline as a cleaning agent.
Explosive Fuel can cause res and severe
burns.
Do not ll fuel tank while engine is hot or
running.
Keihin Two-Barrel Carburetor Components
D
E
F
G
H
I
C
B
Z
J
N
P
O
M
S
T
Q
R
U
K
L
V
X
W
Y
A
AF
AE
AA
AB
AC
AD
A
Carburetor Body
Subassembly
B
Idle Speed
Screw
C
Idle Speed
Spring
D Screw E Ground Lead
F
Retaining
Washer
G
Slow Jet-
Right Side
H
Slow Jet-
Left Side
I
O-ring
(Slow Jet)
J Fuel Bowl
K
O-ring (Fuel
Bowl-Upper)
L
O-ring (Fuel
Bowl-Lower)
M Drain Screw N Bowl Screw O Fuel Solenoid
P Sealing Washer Q Float R Pin S Screw T Float Clip
U
Float Valve/
Inlet Needle
V
Main Nozzle-
Right Side
W
Main Nozzle-
Left Side
X
Main Jet-
Right Side
Y
Main Jet-
Left Side
Z Choke Dust Cap AA Choke Shaft AB Spring AC Bushing AD Choke Lever
AE Choke Plate AF
Choke Plate
Screw
Fuel System
24
24 690 06 Rev. JKohlerEngines.com
