8.17
Section 8
Electrical System and Components
8
Figure 8-22.
10 Amp Charging System
Recoil Start Only
Oil Sentry™ System.
Rectifier-
Regulator
W
W
RRB
WW
BR R
R
B
W
W
WW
Stator
Ground
Ground
Ground
Ignition
Module
Spark
Plug
Oil
Sentry™
Gauge
B
L
BW
BW
Y
Y
Oil Sentry™
LIght
R
B
Ground
Oil
Warning
Unit
Stop
Switch
BW
R
BW
B
Ground
B
