Kohler Command Pro ECV880 User Manual

Specifi cations
14
19 690 01 Rev. --KohlerEngines.com
CLEARANCE SPECIFICATIONS
3
ECV850 ECV860 ECV870 ECV880
Piston, Piston Rings, and Piston Pin Continued
Thrust Face O.D.
7
New
Max. Wear Limit
85.956/85.974 mm (3.3841/3.3848 in.)
85.82 mm (3.3787 in.)
Piston Thrust Face-to-Cylinder Bore
7
Running Clearance
New 0.026/0.069 mm (0.0010/0.0027 in.)
Valves and Valve Lifters
Intake and Exhaust Valve Lash 0.050/0.127 mm (0.0020/0.0050 in.)
Tappet to Crankcase Running Clearance 0.013/0.073 mm (0.0005/0.0029 in.)
Intake Valve Stem-to-Valve Guide Running Clearance 0.038/0.076 mm (0.0015/0.0030 in.)
Exhaust Valve Stem-to-Valv e Guide Running Clearance 0.050/0.088 mm (0.0020/0.0035 in.)
Intake Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.132 mm (0.2808 in.)
Exhaust Valve Guide I.D.
New
Max. Wear Limit
7.038/7.058 mm (0.2771/0.2779 in.)
7.157 mm (0.2818 in.)
Guide Reamer Size
Standard
0.25 mm O.S.
7.048 mm (0.2775 in.)
7.298 mm (0.2873 in.)
Intake Valve Minimum Lift 9.35 mm (0.3681 in.)
Exhaust Valve Minimum Lift 9.35 mm (0.3681 in.)
Nominal Valve Face Angle 45°
3
Values are in Metric units. Values in parentheses are English equivalents.
7
Measure 11 mm (0.4331 in.) above bottom of piston skirt at right angles to piston pin.
