EFI SYSTEM
62 690 13 Rev. A KohlerEngines.com
Wiring Harness
EFI Wiring Diagram 8-Terminal Connector
A Red B Red/Black C Red/White D Yellow E Light Green
F Dark Green G Dark Blue H Purple I Pink J Tan
K White L Grey M Black N Stator O Rectifi er-Regulator
P 30A Fuse Q Battery R Fuel Pump S 8-Terminal Connector T Starter Motor
U Oil Pressure Switch V MIL (Optional) W 10A Fuse X Black Connector Y Grey Connector
Z Fuel Injector #1 AA Fuel Injector #2 AB Ignition Coil #1 AC Ignition Coil #2 AD
Crankshaft Position
Sensor
AE Oxygen Sensor AF
Throttle Position
Sensor
AG TMAP Sensor AH
Oil Temperature
Sensor
AI Diagnostic Connector
AJ Grey/Blue AK
Electronic Governor
only
AL Red/Yellow AM Orange AN Tan (MIL Ground)
AB AB ABC ABC 1 2 DABC
12
19
1018
19
1018
BD
A
C
CAB
12312
4
A
H
B
G
C
F
D
E
DABC
C
G B F
B
B M
B
H
H D B F
H
M
G
M
L
L M
E F
M
J
K
M G
B
K
W
AP
H
I
V
W
O
Y
M
A
N
X
Q
R
T
A
U
Z
AA
AB
AC
AD
AE
AF
AG
AH
AI
G
F
S
M
B
AK
AJ
AL
AM
AN
A
M
