Electrical System
60 62 690 13 Rev. AKohlerEngines.com
A
H
B
G
C
F
D
E
CB
E
D
A
R
I
Q
F
O
M
K
N
P
D
U
G
J
S
T
L
O
H
H
H
E
B
C
A
A To Starter B ECU Power C 12V Constant D
Switch Power
Accessories
E Ground to Kill F Key Switch G Ground H Yellow
I MIL J Oil K Starter L Red
M 15 Amp Fuse N Green O White P 8-Pin Connector
Q 5-Pin Connector R Tan S Red with White Stripe T Blue
U 25 Amp Fuse
Wire Diagram-8-pin Connector and Key Switch Auxiliary Harness
