Kohler Command Pro EFI ECH980

88
Reassembly
KohlerEngines.com 62 690 13 Rev. A
Cylinder Head Components
K
H
B
C
D
A
G
E
F
I
J
L
M
O
P
Q
R
H
F
E
K
L
M
N
N
Style B Style A
T S
A Gasket B Valve C Cylinder Head D Spark Plug
E Valve Stem Seal F Valve Spring G Pipe Plug H Hydraulic Lifter
I
Valve Spring
Cap
J Valve Spring Keeper K Push Rod L Rocker Arm
M Rocker Arm Pivots N Rocker Arm Screw O Valve Cover Gasket P Valve Cover
Q Grommet R Screw S
Hydraulic Lifter
Style A (Ribbed)
T
Hydraulic Lifter
Style B (Smooth)
