Kohler Confidant ZT740

Starter System
4316 690 01 Rev. -- KohlerEngines.com
RETRACTABLE STARTERS
WARNING
Retractable starters contain a powerful, recoil spring that is
under tension. Always wear safety goggles when servicing
retractable starters and carefully follow instructions in
Retractable Starter for relieving spring tension.
Uncoiling Spring can cause severe injury.
Wear safety goggles or face protection when
servicing retractable starter.
Retractable Starter Components
A
B
C
D
F
G
I
E
J
H
A Center Screw B Drive Plate C Friction Spring D Drive Pawl (Dogs)
E Drive Pawl Springs F Pulley G Recoil Spring H Starter Rope
I Starter Handle J Double Left-Hand Knot
