Kohler Courage XT-6 Service Manual

8.9
Section 8
Disassembly
8
Remove Flywheel Brake Assembly
ȱ ŗǯȱ ȱȱȱ¡ȱĚȱȱȱȱ
Ě¢ȱȱ¢Dzȱȱȱǯȱȱ
Figure 8-33.
Remove Spark Plug
1. Remove the spark plug from the cylinder head.
See Figure 8-32.
Figure 8-32. Removing Spark Plug.
Figure 8-33. Removing Flywheel Brake Assembly.
Remove Jam Nuts and Pivots
1. Use a socket and wrench to remove the jam nuts
and the rocker-arm pivots from the rocker studs.
See Figure 8-35.
Remove Valve Cover
ȱ ŗǯȱ ȱȱȱ¡ȱĚȱȱȱȱȱ
cover.
2. Remove the cover and the gasket. See Figure 8-34.
Figure 8-34. Removing Valve Cover.
Figure 8-35. Removing Jam Nuts and Pivots.

Kohler Courage XT-6 Specifications

General

Displacement	149 cc
Compression Ratio	8.5:1
Fuel Type	Unleaded gasoline
Starter Type	Recoil
Engine Type	4-Cycle, OHV, Single Cylinder
Oil Capacity	0.6 L (20 fl. oz.)
Ignition System	Electronic
Fuel Tank Capacity	1.1 L (37 fl. oz.)
