Kohler Curtis AC F2-C User Manual

7 — DIAGNOSTICS AND TROUBLESHOOTING
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 226
Table 24 Fault Code Troubleshooting Chart, cont’d
FLASH
CODE
FAULT NAME
(Curtis Integrated Toolkit™)
POSSIBLE CAUSES SET/CLEAR CONDITIONS FAULT ACTIONS
8-2
0x82
PDO Mapping Error
PDO_Mapping_Error
0x2542
Fault Type(s): 1
1. The PDO Map has too many data
bytes assigned or has objects
mapped that are not compatible.
2. Adjust PDO Settings. See
Programmer » Application Setup »
CAN Interface » PDO Setups.
Set: Incorrect PDO map detected.
Clear: Reset Controller.
PDO message disabled.
Fault Action:
None, unless a fault action
is programmed in VCL.
Dual Drive
Same, both motors
8-3
0x83
Internal Hardware
Internal_Hardware
0x2835
Fault Type(s):
Curtis hardware code.
Internal controller fault detected. Set: Internal controller
fault detected.
Clear: Reset Controller.
ShutdownVehicle:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
FullBrake
ShutdownPump
Dual Drive
Same, both motors
8-4
0x84
Motor Braking Impaired
Motor_Braking_Impaired
0x211A
Fault Type(s): 1
1. Battery overcharged, excessive
motor or controller heating, or
misadjusted parameters.
2. Motor braking was impaired
beyond a safe threshold.
Set: OverallCutback 0x32D9
fell below Motor_Braking_
Impaired_Threshold for Motor_
Braking_Impaired_Time during
regen (braking).
Clear: Reset interlock.
ShutdownInterlock:
Dual Drive
This Motor:
ShutdownInterlock
Other Motor:
ShutdownInterlock
8-7
0x87
Motor Characterization Error
Motor_Characterization
0x2850
Fault Type(s):
1 Failure to determine encoder
pulses. Must be set manually.
72 Temp sensor fault.
73 Motor hot.
74 Controller temperature
cutback.
76 Undervoltage cutback.
77 Overvoltage cutback.
78 Encoder not reading
properly.
79 Current Regulator Tuning out
of range.
80 Current Regulator Tuning out
of range.
81 Encoder signal seen but step
size not auto-detected, it
must be set manually.
82 Aborted commissioning.
83 Sensor signal too noisy for
characterization.
84 Motor not rotating, Sin/Cos
sensor voltages out of
spec, or Multiturn Sensor
setting incorrect.
85 Sensor signal too noisy for
characterization.
Motor characterization failed during
characterization process. The fault
type indicates the cause.
Type 84:
During commissioning, if the Type
84 fault occurs, check that the
Sin/Cos signal voltages at their
maximums and minimums have
differences less than 78mV. (i.e.,
that |Sinmax Δ Cosmax| < 78mV
and the |Sinmin Δ Cosmin| < 78mV).
If the differences are greater than
78mV (e.g., 100mV), it will trigger
the Type 84 fault and abort the
motor characterization routine.
Types are also listed in Chapter 6,
Table 21.
Set: Motor characterization
failed during the motor
characterization process.
Clear: Reset Controller.
ShutdownVehicle:
ShutdownMotor
ShutdownMainContactor
ShutdownEMBrake
ShutdownThrottle
FullBrake
ShutdownPump
Dual Drive
Same, both motors
