4 — PROGRAMMABLE PARAMETERS
Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC
pg. 118
CONTROLLER SETUP — INPUTS MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Analog 19 menu
Analog 19 Type
Analog_Input_19_Type
0x3311 0x00
Enumeration
0 – 3
Voltage Congure the Analog 19 input by throttle or load type.
0 – Voltage (Hall-effect or voltage throttle)
1 – 3-Wire Pot Wiper (3-wire resistive potentiometer throttle)
2 – 2-Wire Pot Wiper (2-wire resistive potentiometer throttle)
3 – Voltage with Supply (a non-throttle load alternative)
Parameters for Analog 19 Voltage selection Reference the Voltage Throttle section, Chapter 6.
Analog 19 Type
Analog_Input_19_Type
0x3311 0x00
Voltage
(selection menu)
– Selecting the Voltage option opens the menu to its corresponding
monitor variables and the low/high parameters.
Voltage
Analog_Input_Volts_19
0x3B60 0x00
–327.68 – 327.67V
–32768 – 32767
Read Only The analog voltage at the analog 19 input (Input 19).
Percent
Analog_Input_Percent_19
0x3B62 0x00
0.0 – 100.0 %
0 – 1000
Read Only The percentage of the voltage at the input pin is based upon the
High and Low settings, i.e., the percent of:
[(analog_input_volts_19) – (analog_input_19_low)] /
[(analog_input_19_high) – (analog_input_19_low)]
Voltage Throttle usage: Reference the Forward Min/Max &
Reverse Min/Max Input parameters located in the Application
Setup » Throttle menu.
Brake input usage: Reference the Brake Min/Max Input
parameters located in the Application Setup » Brake menu.
Low
Analog_Input_19_Low
0x330B 0x00
0.0 – 11.0V
0 – 1100
0.0V The minimum input voltage before a fault is declared. When the
Analog 19 Type selection is voltage, this set point represents the
0% point for the normalized input.
Triggers the Throttle Input fault (0x2210) when the voltage reading
is below this input voltage reading, if Throttle_Source = 19.
Triggers the Brake Input fault (0x2310) when the voltage reading
is below this input voltage reading, if Brake_Source = 19.
High
Analog_Input_19_High
0x330C 0x00
0.0 – 11.0V
0 – 110
11.0V The maximum input voltage before a fault is declared. When the
Analog 19 Type selection is voltage, this set point represents the
100% point for the normalized input.
Triggers the Throttle Input fault (0x2210) when the voltage reading
is above this input voltage reading, if Throttle_Source = 19.
Triggers the Brake Input fault (0x2310) when the voltage reading
is above this input voltage reading, if Brake_Source = 19.
Fault Tolerance
Analog_Input_19_Fault_
Tolerance
0x337B 0x00
0.0 – 11.0V
0 – 1100
0.0V Species the voltage threshold above the congured high limit
or below the low limit, exceeding this results in an analog out of
range fault.
For example, if High = 9.6V, Low = 1V and Tolerance = 0.2V, an
input voltage between 1V to 9.6V is mapped to 0–100%.
Voltages above 9.8V (9.6 + 0.2) or below 0.8V (1V – 0.2V) trigger
the fault.
Quick Links:
Voltage rottle p.166
3-Wire rottle p.165
2-Wire rottle p.165
Fig. 13 p.17
