4 — PROGRAMMABLE PARAMETERS
pg. 147
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
MOTOR SETUP— TEMPERATURE SENSOR - SENSOR MAP MENU, cont’d
PARAMETER ALLOWABLE RANGE DEFAULT DESCRIPTION
Temperature 0
Temp_0
0x368E 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_0 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 1
Temp_1
0x368F 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_1 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 2
Temp_2
0x3690 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_2 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 3
Temp_3
0x3691 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_3 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 4
Temp_4
0x3692 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_4 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 5
Temp_5
0x3697 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_5 resistance.
Consult the temperature sensor datasheet for this value.
Temperature 6
Temp_6
0x3698 0x00
– 3276 – 3276°C
– 3276 – 3276
0°C The user dened motor temperature at the corresponding
Sensor_6 resistance.
Consult the temperature sensor datasheet for this value.
Offset of Windings Due to
Sensor Heating
MotorTemp_Sensor_Offset
0x3687 0x00
–20 – 20°C
– 200 – 200
0°C Often the motor temperature sensor is in the motor at a location
with a known offset to the critical temperature; correct the offset
with this parameter.
Use this parameter to correct a known offset in the sensor itself.
Note: This parameter (0x3687) is also in the temperature sensor
menu.
