5 — SYSTEM MONITOR MENU
pg. 155
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
SYSTEM MONITOR / CONTROLLER MENU: CUTBACKS
VARIABLE DISPLAY RANGE DESCRIPTION
Motor Temperature Cutback
MotorTempCutback
0x3439 0x00
0 – 100 %
0 – 4096
Displays the current available as a result of the motor temperature cutback
function. A value of 100% indicates no cutback in current.
Controller Temperature Cutback
ControllerTempCutback
0x3437 0x00
0 – 100 %
0 – 4096
Displays the current available as a result of the controller temperature
cutback function. A value of 100% indicates no cutback in current.
Undervoltage Cutback
UnderVoltageCutback
0x343B 0x00
0 – 100 %
0 – 4096
Displays the current available as a result of the undervoltage cutback
function. A value of 100% indicates no cutback in current. Does only limit
drive current, but does not affect regen current limit.
Overvoltage Cutback
OverVoltageCutback
0x343A 0x00
0 – 100 %
0 – 4096
Displays the current available as a result of the overvoltage cutback
function. A value of 100% indicates no cutback in current. Does only limit
regen current, but does not affect drive current limit.
LF Cutback
LF_Cutback
0x4F5C 0x00
0 – 100 %
0 – 4096
Displays the current available as a result of the low motor speed
(electrical-frequency) cutback function.
A value of 100% indicates no cutback in current.
Battery Current Cutback
BatteryCurrentCutback
0x3C05 0x00
0.0 – 100.0 %
0 – 4096
Battery current cutback percent. 100% is no cutback, 0% is full cutback.
Overall Cutback
OverallCutback
0x32D9 0x00
-1000 - 1000°C
-1000 - 1000
The accumulated controller cutback.
Traction FET Max Temp
Max_Traction_FET_Temp
0x33DF 0x00
-1000 - 1000 °C
-1000 - 1000
Estimated maximum FET temperature from thermal model.
Traction FET Max Temp Low
FET_Max_Temp_Low
0x4F8D
–50 – 200°C
– 50 – 200
Traction FET Junction Temperature at which the controller begins cutting
back current.
Traction FET Max Temp High
FET_Max_Temp_High
0x4F8E
–50 – 200°C
– 50 – 200
Traction FET Junction Temperature at which the controller allows zero current.
* Note that the displayed Pump FET Temp variables do not apply to the non-pump controllers.
SYSTEM MONITOR / CONTROLLER MENU: MOTOR TUNING
VARIABLE DISPLAY RANGE DESCRIPTION
Motor RPM
Motor_RPM
0x352F 0x00
–30000 – 30000 rpm
–30000 – 30000
Motor speed in revolutions per minute (rpm).
Base Speed Captured
Base_Speed_Captured
0x352B 0x00
0 – 65535 rpm
0 – 65535
Displays the value of the motor’s base speed captured in the most
recent acceleration. Use this value to set the FW Base Speed
parameter using the FW Base Speed set procedure or the ACIM motor
characterization procedure.
Test Field Current
Test_Field_Current
0x3092 0x00
0.0 – 800.0 Amps
0 – 8000
The Field Test Current reading during the ACIM motor autocharacterization
procedure. See Chapter 6, Commissioning – Automated ACIM (motor)
Characterization Procedure.
