5 — SYSTEM MONITOR MENU
pg. 157
Return to TOC Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022
SYSTEM MONITOR MENU: VEHICLE MENU
VARIABLE DISPLAY RANGE DESCRIPTION
Vehicle Speed
Vehicle_Speed
0x37DD 0x00
–3276.8 – 3276.7
–32768 – 32767
Vehicle speed in units of MPH or KPH depending on the setting of the Metric
Units parameter.
Vehicle Odometer
Vehicle_Odometer
0x37DA 0x00
0.0 – 10000000.0
0 – 100000000
Vehicle distance traveled, in units of miles or km, depending on the setting
of the Metric Units parameter in the Vehicle parameters menu.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
Trip Odometer 1
Trip_Odometer_1
0x37D7 0x00
0.0 – 10000000.0
0 – 100000000
Vehicle distance traveled, in units of miles or km, depending on the setting
of the Metric Units parameter in the Vehicle parameters menu.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
Trip Odometer 2
Trip_Odometer_2
0x37D8 0x00
0.0 – 10000000.0
0 – 100000000
A second vehicle distance traveled variable, and works identically to Trip
Odometer 1.
Vehicle Acceleration
Vehicle_Acceleration
0x37D9 0x00
0.000 – 10.000 g
0 – 10000
Vehicle acceleration. This is a calculated value. Set the Speed to RPM
parameter correctly, for an accurate measurement.
Time to Speed 1
Time_to_Capture_Speed_1
0x37D3 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to go from zero rpm to the programmed Capture
Speed 1 during its most recent such acceleration.
Time to Speed 2
Time_to_Capture_Speed_2
0x37D4 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to go from zero rpm to the programmed Capture
Speed 2 during its most recent such acceleration.
Time Between Speeds
Time_Between_Capture_Speeds
0x37CF 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to go from programmed Capture Speed 1 to
programmed Capture Speed 2 during its most recent such acceleration.
Time to Dist 1
Time_to_Capture_Distance_1
0x37D0 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to travel from zero rpm to the programmed
Capture Distance 1 during its most recent such trip.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
Time to Dist 2
Time_to_Capture_Distance_2
0x37D1 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to travel from zero rpm to the programmed
Capture Distance 2 during its most recent such trip.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
Time to Dist 3
Time_to_Capture_Distance_3
0x37D2 0x00
0.00 – 128.00 s
0 – 32000
Time taken for the vehicle to travel from zero rpm to the programmed
Capture Distance 3 during its most recent such trip.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
Braking Distance Captured
Braking_Distance_Captured
0x37C0 0x00
0.0 – 1000000.0
0 – 40000000
Distance traveled by the vehicle starting with vehicle braking (initiated
by throttle reversal, VCL_Brake, or interlock braking) and ending when
Motor_RPM = 0. Units are meters or feet, depending on the setting of the
Metric Units parameter.
For accurate distance measurements, the Speed to RPM parameter must be
set correctly.
