7 — DIAGNOSTICS AND TROUBLESHOOTING

Curtis AC F2-A, F4-A, F6-A Motor Controllers – FOS 4.5 – April 2022 Return to TOC

pg. 204

Flash Code Fault Name CAN Index Page

3-9 0x39 Main Contactor Did Not Close 0x2221 215

3-10 0x3A Motor Setup Needed 0x2103

216

4-2 0x42 Throttle Input 0x2210

4-4 0x44 Brake Input 0x2310

4-6 0x46 NV Memory Failure 0x2830

217

4-7 0x47 HPD Sequencing 0x2211

4-7 0x47 Emer Rev HPD 0x2331

4-9 0x49 Parameter Change 0x2813

4-10 0x4A EMR Switch Redundancy 0x2817

218

5-1 0x51 User 1 Fault thru User 32 Fault 0x2710

5-2 0x52 User 2 Fault 0x2711

5-3 0x53 User 3 Fault 0x2712

5-4 0x54 User 4 Fault 0x2713

5-5 0x55 User 5 Fault 0x2720

5-6 0x56 User 6 Fault 0x2721

5-7 0x57 User 7 Fault 0x2722

5-8 0x58 User 8 Fault 0x2723

5-9 0x59 User 9 Fault 0x2730

6-1 0x61 User 10 Fault 0x2731

6-2 0x62 User 11 Fault 0x2732

6-3 0x63 User 12 Fault 0x2733

6-4 0x64 User 13 Fault 0x2740

6-5 0x65 User 14 Fault 0x2741

6-6 0x66 User 15 Fault 0x2742

6-7 0x67 User 16 Fault 0x2743

5-10 0x5A User 17 Fault 0x2750

5-11 0x5B User 18 Fault 0x2751

5-12 0x5C User 19 Fault 0x2752

219

5-13 0x5D User 20 Fault 0x2753

5-14 0x5E User 21 Fault 0x2760

5-15 0x5F User 22 Fault 0x2761

6-10 0x6A User 23 Fault 0x2762

Table 22 Troubleshooting Chart Index, cont’d
