30 TT-1625 7/17
11. Configure the DEC 550 and DEC 6000
controllers for the remote serial
annunciator.
Note: Refer to the DEC 550 (TP-6200) or DEC 6000
(TP-6750) controller operation manual as
needed.
11.1 Replace the controller cover and hardware.
11.2 Press the Reset Menu key on the controller
keypad.
11.3 Go to Menu 14, Programming Mode, and press
the down arrow key to Programming Mode.
If Programming Mode—Local is shown, go to
step 11.8.
If Programming Mode—Local is NOT shown,
press the right arrow key to select Local. Press
YES and the Enter key.
11.4 Enter the access code. The factory default
access code is the number 0. Press the Enter
key.
11.5 Press the Reset Menu key on the controller
keypad.
11.6 Go to Menu 6, Time and Date, and set the correct
time and date.
11.7 Press the Reset Menu key on the controller
keypad.
11.8 Go to Menu 13, Communications, and press the
right arrow key to Protocol—Modbusr.
11.9 Set the controller Modbusr address to #1 by
pressing the down arrow key to Address. Enter
number 1 and the Enter key.
11.10 Press the down arrow k ey to Baud Rate.
If 19200 is shown, go to step 11.12.
If 19200 is NOT shown, press the right arrow key
to select 19200. Press YES and the Enter key.
11.11 Press the Reset Menu key on the controller
keypad.
11.12 Go to Menu 14, Programming Mode, and press
the down arrow key to Programming Mode—
Local.
11.13 Press the right arrow key to Programing Mode-
Off. Press YES and the Enter key,
11.14 Enter the access code. The factory default
access code is the number 0. Press the Enter
key.
12. Configure the DEC 3000/DEC 3500
controllers for the remote serial
annunciator.
The Decision-Makerr 3000 and 3500 controllers default
to a 19200 baud rate and to a Modbusr address #1. If
the Modbusr settings need to be altered, use
SiteTecht software to make the configuration changes.
13. Configure the DEC 8000 controllers for
the remote serial annunciator.
On the Decision-Makerr 8000 controller, use the
controller menus to change the setpoints shown in
Figure 52. Refer to the controller operation manual for
instructions on changing settings.
For R S-485 port 2, the internal converter must be
enabled and the Modbusr communication speed must
be set to 19200 bps.
Setpoints Setting Selection
Contr. address 1 (default)
RS232(2) mode 0 - DIRECT (default)
RS232(2) MBCSpd 1 - 19200
RS485(2) conv. ENABLED (default)
Figure 52 DEC 8000 Configuration
SiteTecht Software Settings
After the RSA III master and RSA III slaves are installed,
use the SiteTecht software to set up each RSA III.
Note: The RSA III requires a power source to P37. Use
either the engine starting batteries or a 120 VAC
to 12 VDC adapter when programming changes.
The following information assumes the technician has
downloaded the SiteTecht software from Tech Tools
onto a PC laptop and is connected to the respective
RSA III using a USB 2.0 cable, A Male to Mini B Male, 5
pin.
See Figure 53 for SiteTecht software sample screen.
The shaded entries are read only. The top of the screen
provides the user with the ability to update firmware and
reset to factory defaults. There is a pull down screen for
showing parameters with expand all and collapse all
features. The user can cut, copy, and/or paste entries
and then either apply or discard the changes.
Modbusr is a registered trademark o
f
Schneider Electric.
