1. Battery charger
2. Negative (–) battery terminal
3. Positive (+) battery terminal
4. Dual-charger harness adapter
GM95017
1
2
3
4
2 chargers – 1 charger for each set of batteries
(optional setup with dual-charger harness adapter)
1 charger for either 1 or 2 batteries (typical setup)
2 chargers – 1 charger for each battery
(optional setup with dual-charger harness adapter)
1
1
2
3
2
3
2
3
1
1
2
3
2
3
2
3
2
3
4
Figure 3 Systems Diagram
