Reassembly
KohlerEngines.com 14 690 10 Rev. --
External Engine Components
B
D
F
L
A
P
Q
C
O
K
J
E
G
H
E
F
I
M
N
A
Engine Cover and
Retractable Starter
B Retractable Starter C Blower Housing D Lock Nut
E Muffl er Guard F Muffl er G Exhaust Stud H
Muffl er Gasket (Heat
Defl ector)
I Shoulder Screw J Spark Plug Lead K Breather Hose L
Air Cleaner Base
Gasket
M Air Cleaner Base N Nut O Paper Element P Precleaner
Q Air Cleaner Cover
